Description
The 2304C ECO motor from Dualsky has 1450kv of power and is a great choice for indoor RC planes. This motor comes with propeller and motor mounts, in addition to gold plugs and screws.
Features
- Classic Dualsky five-spoke back cover
- Traditional Dualsky colour matching, anodized and matte finish
- Multi-surface rotating laser markings
- Motor structure strength increased by 25% over previous generations
- Optimised stress distribution
- Tough main shaft
- High precision
- Splashproof (please note, ball bearing is not waterproof)
Specification
- KV: 1450
- Turns: 23
- Weight: 23
- Dimensions: 28.5mm x 16.7mm
- Slots & Poles: 12N14P
- Ri (mOhm): 230
- Io @ 10V (A): 0.3
- No. of cells (LiPo): 2S, 3S LiPo
- Max Efficiency Current (A): 6
- Max. Burst Current (15S)[A]: 10
- Max. Power(15S)[W]: 120
- Max. Torque [N*M]: 0.079
- Shaft diameter(mm): 3.175
- Mountingholes pitch: 32
- Input Connectors: GC2.0
- Recommended ESC: XC-12 Lite or XC1210BA
- Propeller:
- 2S: 8×4.7E, 9×4.7E
- 3S: 7x4E, 8x4E
- Class: 100-200g airplane
