Description
This is the Dualsky XM6352EA-10 Brusless Motor. The new V3 Dualsky XM6352EA-10 features a new Durotate rotor with an optimised back cover that reduces air noise, a new front cover that offers better heat dissipation and a higher density rotor and shell that reduces vibration. Add to this the use of thicker wire with high-temperature resistance and the net result is more power and improved efficiency.
Features
- Higher grade curved magnets
- High efficiency, high density Silicon steel
- Tighter tolerances allow a smaller air gap between the stator and the rotor
- High grade enamelled silicon coated wire
- Reduced air noise, less drag, more power
- Lightweight
- M8 propellor mount
Specification
- KV: 560
- Slots & Poles: 12N14P
- Ri (mOhm): 7.4
- Io@10V (A): 3.7
- Efficiency Current (A): 60
- Burst Current (15S) [W]: 120
- Peak Power (15S) [A]: 2880
- Peak Torque [N*M]: 2.56
- Battery: 5S or 6S LiPo
- Weight: 515g
- Dimensions: (Dx L) 63.1 x 55mm
- Dimensions of Stator (mm): 5322
- Shaft diameter: 8mm
- Mounting holes: 4-M4, 32/32, 4-M4, 44/44
- Input connectors: DB4
- Reccomended propellers (5S): 15×6, 16×8
- Reccomended propellers (6S): 14×6, 15×8
- Recommended ESC: SUMMIT 120
- Application: 125E, .95-.120 2-stroke OR Up to .140 4-stroke
Includes
- Propeller mount
- Motor mount
- Screws
- Female bullet connectors
- Heat shrink
